KAIWEETS KTI-W01 256 * 192 Thermal Imaging Camera
Fraud Prevention: Your Payment is Safe & Secure.
Terms of use:
1. This product (KAIWEETS Care) is a special service product and cannot be returned.
2. Valid for three year starting from the date of purchase.
3. If the product or its accessories are damaged by non-human factors, we will replace the accessories or product for free (free shipping and free replacement).
4. For kaiweets.com orders only.
5. KAIWEETS Tools has the final right to explain the terms.
High Resolution, Accurate Measurements: The Kaiweets KTI-W01 thermal imaging camera features 256x192 ultra-high resolution, thermal sensitivity ≤ 50mk, temperature resolution up to ±1°F, and a temperature measurement error of ±2°C or ±2%. Three temperature measurement modes center point/maximum temperature/minimum temperature, fast 25Hz frame rate and wide temperature range -20°C to 550°C (-4°F to 1022°F) with high resolution. Accurate measurements allow you to identify potential problems early and diagnose issues reliably!
3 Image Modes and 5 Color Palettes: Mixed with 0.3 megapixel visible light, the KTI-W01 thermal camera offers 3 image modes - infrared, visible light, and fusion - to meet different usage scenarios. A variety of color palettes are available for you to choose the ideal color scale for your work.
Free PC Software Upgrade: The Kaiweets KTI-W01 can be connected to a Windows PC via USB for online analysis, detecting temperature changes and supporting point and line surface temperature measurements. 32G of eMMC (28G actual) flash memory can hold >300,000 images, and you can stream the device to a laptop or PC for offline temperature measurement and analysis. PC for offline temperature measurement, analyze saved images, exporting data reports, and dig deeper into the data.
Supports Video Recording With a 3.2" Color Screen: Powerful one-touch photo viewing and video recording allows you to share the photos you've taken to your computer. The KTI-W01 handheld thermal camera has a large 3.2" screen that lets you see colors and objects clearly for extreme accuracy. Much better than other blurry, poorly defined images.
Superior Battery Life: Built-in 3500mAh rechargeable Li-ion battery can support up to 6-8 hours of continuous work, the super long service life allows you to easily deal with high-intensity measurement work. Perfect for home inspections, missing insulation, air leaks, water damage, facility maintenance, HVAC troubleshooting, and specialized inspections of electromechanical systems! The auto shut-off feature ensures you won't run out of power on important jobs.
Sturdy Quality & Hassle-Free Warranty: The KTI-W01's ergonomic grip makes it easy to hold and the IP54 waterproof and dustproof design. Comes with a 3-year warranty and lifetime technical support. Package includes: thermal imaging camera*1, data cable*1, protective case*1, manual*1, 5V charger*1."
| KTI-W01 | Parameters |
|---|---|
| Infrared Resolution | 256x192 |
| Infrared Response Band | 8 to14μm |
| Measurement Temperature Range | -20℃ to +550℃ (-4℉ to 1022℉) |
| Measurement Accuracy | -15℃ to 550℃ ±2℃ or ±2%; -20°C to -15°C ±4°C |
| Measurement Resolution | 0.1℃ |
| Measurement Mode | Center point/hot and cold spot tracking |
| Color Palette | Spectrum, Iron, Cool, White, and Black |
| Emissivity Setting | Adjustable from 0.01 to 1.00 |
| Visible Light Resolution | 640x480 |
| Display Size | 3.2inch (240×320) |
| Photo Display Mode | Infrared/visible light/dual light fusion |
| Work Temperature | -10℃ to +50℃ (14℉ to 122℉) |
| Storage Temperature | -20℃ to +60℃ (-4℉ to 140℉) |
1 x KTI-W01 Thermal Imager
1 x Type-C Data Cable
1 x User Manual
1 x 5V Charger
1 x Packaging Box
1 x Durable EVA Bag
Developed for KTI-W01
Download and connect, simply and easily.
Quickly start the device with KAIWEETS ultra-intuitive, user-friendly interface.
KTI-W01 APP Download
KTI-W01 Manual Download
5 Color Palettes
Powerful one-touch photograph and video recording function, so you can share the photos and video taken to your computer. 5 color palettes let you choose the ideal color to read the temperature differences in your scene, very suitable for high thermal contrast and identify temperature differences! Which can be used in a variety of applications including house inspection, automotive, outdoor hunting, security, fire, industrial inspection, etc.
Multiple Temperature Points
The infrared cameras thermal imaging device automatically tracks and displays the highest, lowest, and center point temperatures, allows users view temperature differences more visually. Has a function such as adjust the emissivity, adjust the emissivity allows you to take more accurate measurements.
8 Hours Run Time
The built-in 3500mAh rechargeable Li-ion Battery can support 8-hour runtime, Can use anytime with no need to worry about low battery.
Data Transfer USB Charging
You can transfer photos to a computer via the USB cable while charging the Thermal Imaging camera. Analyzer for PC allows you to batch analyze thermal images and generate professional reports and custom report templates for your different purposes.
